Detailed design and engineering follows a process which entails conceptual design, embodiment design and detail design, and when performed professionally, eventually it results in a well-designed solution. Conceptual design is phase-one of detailed design and engineering in which drawings are the main output. The drawings produced are often quite simple ideas with little detail, but the aim of the conceptual phase is to commit ideas to paper. The Embodiment phase of the detailed design and engineering process starts with the concept and develops it into a workable system that can be further developed. During this phase, engineers will typically follow a framework of clarity, simplicity and safety in achieving the design goal.
Detailed design is the phase where the design is refined, and plans, specifications and estimates are created. Detailed design will include outputs such as 2D and 3D models, P & ID’s, cost build up estimates, procurement plans etc. This phase is where the full cost of the project is identified.
The fact that detailed design and engineering process has a strong impact on the overall project cost it is also the stage in which the most cost saving can be made. Equally if the phased process described above is done poorly it can have a major negative impact on the overall project success.
We offer state of the art Detailed Engineering Services to ensure optimum quantities, work-volumes, constructability, operability, maintainability for multi-platform engineering industries. We are capable of full spectrum engineering services inclusive of studies, approval, planning, design, and implementation.
We have the requisite domain knowledge experts, cutting edge software tools and specially developed applications for delivering intricate engineering services. These include a seamless integration of basic engineering through a common design database, which provides consistent and correct data in all the design deliverables and design cycles.
We provide the detailed engineering services by delivering intelligent engineering designs and the associated documentation. This is achieved through the extensive use of integrated engineering workflows, as well as multi-platform engineering applications for the design and analysis of mechanical, electrical, electronics, medical & pharma products, piping, instrumentation and structural activities. We extract all the essential information from the basic engineering drawings and calculations to provide the exact drawings in detail for all production, fabrication & erection items and in turn the details of entire project along with the precise bill of quantities and specifications for each of the equipment.
We prepare the detailed Layout, Drawings, Detailed Plot Plans, Specifications, Datasheets for Mechanical, Electrical, Electronics & Instrument Equipment’s, Detailed Piping Drawings which includes Isometrics and Stress Calculations, Detailed Drawings related to Electrical Facilities and Instruments, Detailed Calculations and Reports for all Equipment’s, Detailed Construction and Fabrication Drawings, Detailed Drawings for all major and miscellaneous Structural Items, complete PDMS model includes Mechanical, Piping, Electrical, Electronics, Instrumentation and Structural.
Our team is familiar with various international codes and standards like ANSI, ASME Section VIII Div-1 and Div-2, EN13445, TEMA, API, KSA, SMACNA, DW and IS as well as wind and seismic analysis to IBC, UBC, ASCE, and NBC.
